Compatible Vehicles
Features
- 1. Features with heavy duty double convoluted crimped design which allows safe and comfortable load capacity up to 2500 pounds.
- 2. Built to strict quality control standards.
- 3. Designed for Comfort Suspension.
- 4. Bring better handling and ride comfort.
- Notice
- - These air suspension bags are aftermarket ones. They will replace the original air spring bags.
- - Please double check the picture and drawing carefully before purchasing to ensure you will get the right struts.
- -Instruction is not included. Professional installation is recommended
- -Contact us please for whatever we can help
- Notice
- All modifications must be installed by licensed mechanics and in compliance with your local modification regulations
- <div
Condition
100% Brand New
Fit for
- Universal Air Suspension Bags compatible for Ford F150/F250, compatible for GMC Sierra, compatible for Chevrolet Silverado, compatible for Dodge Ram 1500 2500 3500, etc
- (Fits for Most Pickup Trucks, or Classic Car)
Part Number
2E2500
Quantity
1 piece (for rear / front left or right)
Warranty
One year Warranty for any manufacturing defect.
Design Height
212mm
Min Height
110mm
Max Height
240mm
Working Stroke
- 130mm
- Loading Cap. at 3.0bar: 1.48KN
- Loading Cap. at 7.0bar: 6.23KN
Single Air Port Size
1/2-14NPT
Install Hole Size
3/8-16UNC
Top Plate Diameter
113mm
Air Spring Bag Body Diameter
152mm
Capacity
2500 LBS
