Compatible Vehicles
- Compatible for Cummins TRUCK Signature 600 with ISX2 Engine 2001-2007
- compatible for Cummins Dennis Coach Signature 600 Various with ISX2 Engine 2006-2014
Specification
- Turbo Model: HX55W
- Engine Code: ISX2
- Finish: Matte
- Condition: 100% Brand New
- Accessories: You will get what you can see in the pictures exactly
Feature
- * Product Material
- 1. Turbine housing: Ductile iron QT450-10- temperature resistant up to 700℃
- 2. Steel turbine wheel：K418 alloy - high oxidation stability and resistance up to 900℃
- 3. Compressor housing：ZL104 aluminium with lightweight
- 4. Compressor wheel：Cast aluminium blades – superior air tightness & corrosion resistance
- * Product
- 1. OEM size can be directly replaced
- 2. Rich experience in turbo production and own factory
- 3. High-Speed oil seal ring and Precision clearance
- * Technology Advantage:
- 1. 100% balancing Test by TURBOTECHNICS VSR3
- 2. G3-min-Flow VNT Turbo testing
- 3. Advanced Actuator Tester/Programmer
Note
- * Before installing the new turbocharger, the cause that led to the failure of the turbo must be analysed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
- * Please confirm your original turbo PART NUMBER before Purchasing.
- * Professional installation is highly recommended,
- * Before installation, please check the oil supply sufficient, clearnliness the air filter and gasoline , and the gasoline air tightness.
OE/Part number
4046127, 4040844, 4040845, 4040846, 4046132H, 4090042, 409004200, 409004200H, 409004200HX, 4090042H, 4090042HX, 4090042NX, 4090042RX, 4036758, 3596613, 3592545, 3593623, 3593625, 3595069, 3596047, 3596622, 3596623, 3800774, 3800890, 4024854, 4025321, 4037480, 4037481, 4037482, 4046131, 4046132, 404613200, 404613200H, 404613200HX, 4046132HX, 4089768
