Rear Air Suspension Kit Compatible for Fiat Ducato compatible for Peugeot Boxer compatible for Citroen Relay Jumper Air Helper Springs

Compatible Vehicles

• Compatible for Fiat Ducato 1994-2024
• compatible for Citroen Relay 1994-2024
• compatible for Peugeot Boxer 1994-2024
• compatible for Citroen Jumper 1994-2024
• fit for singal rear wheel or twin rear wheel, compatible for FWD or RWD.
• BODY TYPE: Panel van, tipper, motorhome, camper, box van (excluding alco type torsion bars chassis).

Specification

• Condition: Brand New
• Chassis Type: All standard type Chassis
• Placement on Vehicle: Rear left and right
• Max loading：4000 Kg
• Air spring---
• Design height: 172 mm
• Stroke: 140 mm
• Max. Extended: 230 mm
• Min. Compressed: 90 mm
• Minimum height of whole kit: 146 mm
• Maximum height of whole kit: 326 mm
• Air pump---
• Power: 150W
• Output Voltage: 12V
• Maximum Working Voltage: 10bar（1MPa ）
• Package includes（as the picture shows）:
• 2x Air spring
• 1x Air suspension compressor
• 1x Guage
• 4x Mounting bracket
• 1x Air line 8m
• Mounting bolts and Air fittings

Feature

• 1、Stress Test Over 5,000,000 Times：Durable and Safe
• 2、Burst Pressure≥2.0MPa：High Compressive Strength and Less Noise
• 3、100% Air Tightness Guarantee
• 4、Temperature Range ≥ -40℃/ ≤ 70℃ (≥ -40°F/≤ 158°F)：Premium Natural Rubber Material
• 5. 4-Layer reinforcement construction: Enhances air spring load support.
• 6、Use high-quality steel with high load-bearing capacity and long life.
• 7、Excellent and practical bolt-on installation.
• 8、Safe carrying capacity and stability
• 9、Restore the original ride height and improve ride quality
• 10、Ensure our driving comfort and reduce tyre wear.
• 11、Dacromet is a new surface treatment technology that has excellent corrosion resistance compared to traditional electroplating processes.
