Compatible Vehicles
- Compatible for Acura TSX (CL9) 2004-2008
- compatible for Honda Accord (CM3/5/6) Sedan 2003-2007
Introduction
The C1 series is designed for those who want to lower their vehicle without sacrificing daily driving comfort. Enjoy improved handling and a smoother ride. Featuring adjustable height and a preset for optimal damping, this series enables you to reduce ride height while maintaining overall comfort.
Specification
- Front and Rear Top Mounts: Aftermarket top mounts
- Damping Adjustable: Not available
- Height Adjustable: Available, lowering 35-65 mm depending on the vehicle models
- Main spring rate front: 10 kg/mm (560 lbs/in)
- Main spring rate rear: 4 kg/mm (224 lbs/in)
- Main spring length front: 200 mm
- Main spring length rear: 255 mm
- Helper spring rate front:1 kg/mm (56 lbs/in)
- Helper spring rate rear:1 kg/mm (56 lbs/in)
- Helper spring length front:102 mm
- Helper spring length rear:102 mm
- Front spring inner diameter: 62 mm
- Rear spring inner diameter: 62 mm
- Spring Type Front: Linear spring & Helper spring
- Spring Type Rear: Linear spring & Helper spring
- Spring Material: 55CrSi steel
- Shock Body Material: Stainless steel
- Colour: Silver body with golden spring
Dimension
- Package Size: 70.6*50.7*20.7 cm
- Weight: 27700 g
Feature
- 1. The stainless steel shock body offers excellent corrosion resistance and durability, prolonging the lifespan of the coil-overs.
- 2. The factory preset damping and newly designed damping valve will optimise comfort, handling, and performance.
- 3. Aftermarket top mounts guarantee optimal compatibility and reliability, maintaining vehicle comfort and minimizing noise, vibration, and harshness to the greatest extent.
- 4. Height adjustment enables precise tuning of the vehicle's stance, improving comfort and handling for a better driving experience.
- 5. Durable springs enhance shock absorption and provide a smoother ride quality, protecting passengers from the jolts of uneven road surfaces
- 6. High Viscosity Index Damping Oil delivers reliable damping performance and minimizes viscosity fluctuations across a range of temperatures.
- 7. Twin-tube damping technology offers outstanding comfort and stability, ensuring a smooth ride across different road conditions.
- 8. The 45# reinforced steel piston rod offers high strength, durability, and wear resistance for enhanced stability.
- 9. Anodized AL6061 aluminium spring seats and locking rings are lightweight, corrosion-resistant, and strong.
- 10. The extended dust cover protects the damper from dust intrusion and prolongs the damping system's service life.
- 11. High-quality sealing materials effectively prevent damper oil leakage, thus enhancing operational efficiency and reliability.
- 12. The rubber buffer provides excellent elasticity and shock absorption for a comfortable ride.
Package included
- Package included：
- 2 x Front coil-overs
- 2 x Rear coil-overs
- 2 x C spanners
Note
- 1. All modifications must be installed by licensed mechanics and in compliance with your local modification regulations.
- 2. Please ensure all components are tightened with correct torque specifications (which can be found in the vehicle service manual)before and after installation. Any loose nuts, bolts, or locks will cause noise. Do check and tighten before serious problems happen.
- 3. Impact wrench is prohibited during the installation, it will loosen or damage the product.
- 4. Examine the clearance between tyres and suspension. ( The minimum clearance should be 4mm, otherwise, you need to add wheel spacers. Caution: It is not sufficient with torsion beam trailing arm axles)
- 5. We suggest regular maintenance for the coil-over, spray with some WD40 every 3-4 months will keep it smooth and clean, which helps to extend the lifetime.
