H Beam 4340 EN24 Connecting Rods Conrods Con Rod compatible for AudiVW 3.0T Supercharged
SKU: CR-AUD-153
Contact us for a quote
Compatible Vehicles
Compatible for Audi 3.0L TFSI Supercharged DOHC V-6
compatible for Volkswagen 3.0 DOHC V6 TDI Engine
Specification
TÜV Certification Con Rods
Type: Forged 4340 aircraft chrome moly quality steel for racing
H-beam Conrods Quantity: 6 Pieces a set
Bolts: Including Genuine ARP 2000 5/16" bolts
Note: Extra cost for upgrading to ARP L19 bolts
Bolts Size: 5/16"
Tolerance: Balanced to +/- 1 gram in set
Piston Bolt Hole: +-4/1000mm
Power: 600hp ~ 800PS per set
Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
Top acceleration: 7000rpm
warranty:one year warranty for any manufacture defect
Dimensions
Centre to centre length: 153 mm
Big end diameter: 58.85mm
Small end diameter: 22mm (taper)
Big end width: 20.10mm
Small end width: 20.10mm
Feature
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Note
Professional installation is highly recommended (No Instruction Included)
Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
