Compatible Vehicles
- Ford Commercial Transit 2011-2013 787556-5017
Introduction
Looking to boost your car's horsepower? Is your car's original turbocharger not performing well or need replacing? stocks all the best OEM-quality turbochargers and turbo parts to give your car the power, performance, and reliability you deserve. aftermarket replacement turbos provide the perfect solution by delivering a high-quality turbo at a budget-friendly price.
Specification
- Turbo Model: GTB1749VK
- Actuator Type: Electronic Actuator
- Cooling Type: Oil Cooled
- Bearing Type: Journal Bearing / Floating Bearing
- Thrust Bearings: 270 Degrees
- Horse Power: 114KW / 153HP
- Condition: Brand New
- Accessories: You will get exactly as shown in the picture above
- Package Size: 26* 25 * 23 cm
- Package Weight: 7840 g
Feature
- *Product Material
- 1. Turbine housing ：Ductile iron QT450-10- temperature resistant up to 700℃
- 2. Steel turbine wheel：K418 alloy - high oxidation stability and resistance up to 900℃
- 3. Compressor housing：ZL104 aluminium with lightweight
- 4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance
- *Product Performance
- 1. OEM-quality and size with little modification
- 2. Rich experience in turbo production and own factory
- 3. High-Speed oil seal ring and Precision clearance
- *Product Certification
- TÜV and ISO 9001 Certification
- *All necessary gaskets included for ease of installation
- Note: This Turbo is for the rear wheel drive cars (RWD).
Note
- * Please confirm your original turbo PART NUMBER before Purchasing
- * Professional installation is highly recommended
- * Before installing the new turbocharger, the cause that led to the failure of the turbo must be analysed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
OE/Part number
- 787556-5017S, 787556-17, 787556-0017, 7875560017,787556-9017S,
- 787556-5016S, 787556-16, 787556-0016, 7875560016,787556-9016S,
- 787556-5022S, 787556-22, 787556-0022, 7875560022,
- 854800-0001, 854800-1, 854800,
- BK3Q6K682PC, BK3Q-6K682-PC,
- BK3Q6K682PB, BK3Q-6K682-PB,
- BK3Q6K682CB, BK3Q-6K682-CB,
- BK3Q6K682CC, BK3Q-6K682-CC,
- BK3Q6K682HA, BK3Q-6K682-HA,
- 1717628, 1719695, 1760759
Applications
- Compatible for Mazda BT50 2.2L 2011-2021
- Compatible for Ford Ranger (TKE) 2.2TDCI 4x4 110KW ENQJ, GBVAJQJ 2011-2025
- Compatible for Ford Ranger (TKE) 2.2TDCI 110KW ENQJ, GBVAJQJ 2011-2025
- Compatible for Ford Ranger (TKE) 2.2TDCI 118KW GBVAJQJ, T22DD0P 2015-2025
- Compatible for Ford Ranger (TKE) 2.2TDCI 4x4 118KW GBVAJQJ, T22DD0P 2015-2025
- Compatible for Ford Transit Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2TDCI RWD 74KW DRRA, DRRB, DRRC 2011-2014
- Compatible for Ford Transit Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2TDCI RWD 92KW CYRA 2011-2014
- Compatible for Ford Transit Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2TDCI RWD 100KW USRA, USRB 2011-2014
- Compatible for Ford Transit Kasten (FA_ _) 2.2TDCI RWD 74KW DRRA, DRRB, DRRC 2011-2014
- Compatible for Ford Transit Kasten (FA_ _) 2.2TDCI RWD 92KW CYRA 2011-2014
- Compatible for Ford Transit Kasten (FA_ _) 2.2TDCI 4x4 92KW CYRB, CYRC 2011-2014
- Compatible for Ford Transit Kasten (FA_ _) 2.2TDCI RWD 100KW USRA, USRB 2011-2014
- Compatible for Ford Transit Kasten (FA_ _) 2.2TDCI RWD 114KW CVRA, CVRB, CVRC 2011-2014
- Compatible for Ford Transit Pritsche/Fahrgestell (FM_ _, FN_ _, FF_ _) 2.2TDCI RWD 74KW DRRA, DRRB, DRRC 2011-2014
- Compatible for Ford Transit Pritsche/Fahrgestell (FM_ _, FN_ _, FF_ _) 2.2TDCI RWD 92KW CYRA 2011-2014
- Compatible for Ford Transit Pritsche/Fahrgestell (FM_ _, FN_ _, FF_ _) 2.2TDCI 4x4 92KW CYRB, CYRC 2011-2014
- Compatible for Ford Transit Pritsche/Fahrgestell (FM_ _, FN_ _, FF_ _) 2.2TDCI RWD 114KW CVRA, CVRB, CVRC 2011-2014
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI RWD 74KW DRR5 2013-2018
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI RWD 92KW CYR5, USR6 2013-2018
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI 4x4 92KW CY24, CYR5 2013-2018
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI RWD 99KW UHR5 2013-2018
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI RWD 114KW CV24, CVR5, UYR6 2013-2018
- Compatible for Ford Transit V363 Bus (FAD, FBD) 2.2TDCI Allrad 114KW CV24, CVR5 2015-2018
- Compatible for Ford Transit V363 Kasten (FCD, FDD) 2.2TDCI RWD 74KW DRR5 2013-2018
- Compatible for Ford Transit V363 Kasten (FCD, FDD) 2.2TDCI RWD 92KW CYR5, USR6 2013-2018
- Compatible for Ford Transit V363 Kasten (FCD, FDD) 2.2TDCI 4x4 92KW CY24, CYR5 2013-2018
- Compatible for Ford Transit V363 Kasten (FCD, FDD) 2.2TDCI RWD 114KW CV24, CVR5, UYR6 2013-2018
- Compatible for Ford Transit V363 Kasten (FCD, FDD) 2.2TDCI 4x4 114KW CV24, CVR5 2015-2018
- Compatible for Ford Transit V363 Pritsche/Fahrgestell (FED, FFD) 2.2TDCI RWD 74KW DRR5 2013-2018
- Compatible for Ford Transit V363 Pritsche/Fahrgestell (FED, FFD) 2.2TDCI RWD 92KW CYR5, USR6 2013-2018
- Compatible for Ford Transit V363 Pritsche/Fahrgestell (FED, FFD) 2.2TDCI 4x4 92KW CY24, CYR5 2013-2018
- Compatible for Ford Transit V363 Pritsche/Fahrgestell (FED, FFD) 2.2TDCI RWD 114KW CV24, CVR5, UYR6 2013-2018
- Compatible for Ford Transit V363 Pritsche/Fahrgestell (FED, FFD) 2.2TDCI 4x4 114KW CV24, CVR5 2013-2018
Technology Advantage
- 1. 100% balancing Test by TURBOTECHNICS VSR3
- This Turbocharger you will receive has been balanced using the VSR machine technology. Through the comprehensive and high-precision static and dynamic balance detection technology, and reliability.
- 2. G3-min-Flow VNT Turbo testing
- The G3-min-Flow (Air) machine can accurately measure the flow through the VGT turbo and verify that it is set to the OEM factory setting. easily adjust the critical minimum-flow stop to the correct setting before the turbocharger leaves workshop.
- 3. Advanced Actuator Tester/Programmer
- Electronic actuator diagnostic with G3-rea-master can rewrite memory in electronic actuators and also allows to modify operation range of the actuator arm, that includes changing open and close positions of the working angle.
