Forged H-Beam Connecting Rods compatible for Honda ACURA Prelude Accord H22 H22A H22A1 2.2L

Compatible Vehicles

• Compatible for Honda Prelude (1992-2001) – Fits H22A/H22A1 2.2L DOHC VTEC engine
• compatible for Honda Accord 2.2L (1990-2002) – Fits H22A/H22A1 2.2L DOHC VTEC engine
• compatible for Honda Accord 2.3L (1990-2002) – Fits F-series engine (F22/F23), not H22 series
• Pin Type: Floating Pin Piston

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• Clearanced for Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 3/8"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Center to Center: 143.00mm/5.630in
• Approximate Connecting Rod Weight:563g
• Big End Bore Diameter: 51.00mm/2.008in
• Pin End Bore Diameter: 22.00mm/0.866in
• Big End Width：23.75mm/0.935in
• Small End Width: 23.75mm/0.935in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 9000rpm

Packaging

• Quantity: Sold as a set of 4
• Package Size: 28CM*20CM*10CM
