Forged Connecting Rods +ARP Bolts compatible for BMW S38 B35 1988 M5 M6 Conrods 144mm 800HP

Compatible Vehicles

• Compatible for BMW S38 B35 1988 M5 M6
• compatible for BMW S38: straight-6 DOHC piston engine
• S38B35 1986 - 1988 , compatible for BMW E28 M5 (NA spec), compatible for BMW E24 M6 (NA spec),; Compatible for BMW E24 M635CSi with catalytic converter
• S38B36 1989 - 1993 compatible for BMW E34 M5 (NA spec) and Euro spec 1989–1992
• S38B38 1992 - 1996 compatible for BMW E34 M5

Specification

• - TÜV Certification Con Rods
• - Type: Forged 4340 aircraft chrome moly quality steel for racing
• - H-beam Conrods Quantity: 6 Pieces as showing in the picture
• - Bolts: Including ARP 2000 bolts
• - Note: Extra cost for upgrading to ARP L19 bolts
• - Bolts Size: ARP 2000 3/8" bolts
• - Tolerance: Balanced to +/- 1 gram inset
• - Piston Bolt Hole: +-4/1000mm
• - Power: 600hp ~ 800hp per set
• - Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
• - Top acceleration: 9000rpm
• - Warranty: one year warranty for any manufacturing defect

Dimensions

• Centre to centre length: 144mm
• Big end diameter: 52mm
• Small end diameter: 22mm
• Big end width: 24mm
• Small end width: 24mm

Feature

• - Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
• - Designed and processed by CNC machine.
• - All big and small ends are finished with SUNNEN honing machine
• - Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
• - 100% X-rayed, sonic tested and magnafluxed
• - Multi-stage heat treated
• - Shot peened to relieve stress
• - Come with the bronzed bushing suitable for the floating piston pin

Note

• - Professional installation is highly recommended (No Instruction Included)
• - Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
