For JDM compatible for Honda Civic CRX D16 ZC SOHC VTEC Titanizing Connecting Rods and Bolts Conrods
SKU: CR-HON-137A-T
Contact us for a quote
Compatible Vehicles
For JDM compatible for Honda Civic CRX D16 ZC SOHC VTEC D Series：
for 1986–89 compatible for Acura Integra (USA)
for 1986–89 compatible for Acura Integra (Australia)
for 1988–1991 compatible for Honda Civic Si, CRX Si
for 1990-1991 Civic EX (4dr), Civic Wagon RT4WD
for 1988–1991 Civic GTi in New Zealand
for 1988–1989 Civic models in Europe (ED4, ED7)
for 1995 Civic models in New Zealand (EG4)
for 1988–1995 Models in South Africa
for1998–2000 compatible for Honda Civic GX
for 1996–2000 compatible for Honda Civic HX
for 1996 compatible for Honda Civic EX (sedan Peruvian version)
for 1996–2000 compatible for Honda Civic VTI
for 1992–1995 compatible for Honda Civic Si
for 1992–1995 compatible for Honda Civic EX, EX-V
for 1992–1995 compatible for Honda Civic ESi (European Market)
for 1993–1995 compatible for Honda Del Sol Si (US)
for 1993–1996 compatible for Honda Del Sol ESi (European)
for 1992-1995 compatible for Honda Civic RTSi
for 1996–2000 compatible for Honda Civic EX Coupé
for 1991–1993 compatible for Honda Civic Ferio EJ3 (For JDM)
for 1992–1995 compatible for Honda Civic EJ1 (For JDM)
for 1992–1995 compatible for Honda Domani MA4 (For JDM)
for 1993-1997 compatible for Honda del Sol (Si)
Pin Type: Floating Pin Piston
(Note: Please confirm the dimensions before purchase the connecting Rods)
Specification
*Type: Forged 4340 aircraft chrome moly quality steel for racing
*H-beam Conrods Quantity: 4 Pieces as showing in picture
*Bolts: Including ARP 2000 3/8" bolts (Note: Extra cost for upgrading to ARP L19 bolts)
*The connecting rods all include ARP 2000 bolts, which are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi is available as an upgraded product.
*Advertised Horsepower Rating:200HP/piece
*Top acceleration: 9000rpm
*package size：28CM*21CM*10CM
Dimension
Center to center length: 137mm/5.394"
Big end diameter: 48mm/1.890"
Small end diameter: 19mm/0.748"
Big end width: 22.8mm/0.898"
Small end width: 18.2mm/0.717"
Feature
The density of titanium is significantly lower than that of steel, while maintaining considerable strength, which means that it is lighter than steel, but the strength is very similar.
1. Titanizing can further improve the bending strength of the product;
2. Titanizing will not affect the weight of the connecting rod;
3. Provide a wear-resistant layer, which greatly prolongs the service life of the parts;
4. TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED.
5. Material: Titanizing Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing.
6. ARP 2000 bolts ,Optional ARP L19 fasteners available as an upgrade.
7. H-Beam design reduces weight without compromising strength.
8.Heat-treating & Shot-peened for remained consistent and strong, Shot-peened finish to remove potential for stress risers.
9.High precision CNC machined,Precision rod cap alignment dowels.
10.Bores finished to +/- .005mm.
11.Balanced to within +/- 1 g per rod.
12. Each rod is magnetic particle tested to ensure free of flaws.
13.Use X-rayed, sonic tested.
14.Custom Service.
Note
*Professional installation is highly recommended ；
*Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
