EN24 4340 Forged H-Beam Connecting Rods+ARP2000 Bolts compatible for Volvo S60 R 2.5L 143mm

Compatible Vehicles

• Compatible for Volvo S60R (2004–2009) – Fits B5254T2 2.5L Turbo engine
• compatible for Volvo S60 2.5T / 2.5T AWD (2003–2009) – Fits B5254T2 2.5L Turbo engine
• compatible for Volvo V70 II 2.5T / 2.5T AWD (2003–2008) – Fits B5254T2 2.5L Turbo engine
• compatible for Volvo XC70 2.5T AWD (2003–2007) – Fits B5254T2 2.5L Turbo engine
• compatible for Volvo S80 2.5T (2003–2006) – Fits B5254T2 2.5L Turbo engine
• compatible for Volvo XC90 2.5T AWD (2003–2012) – Fits B5254T2 2.5L Turbo engine
• Pin Type: Floating Pin Piston（浮动活塞销）

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• Clearanced for Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 3/8"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Centre to Centre: 143.00mm/5.630in
• Approximate Connecting Rod Weight:596g
• Big End Bore Diameter: 53.00mm/2.087in
• Pin End Bore Diameter: 23.00mm/0.906in
• Big End Width: 25.70mm/1.012in
• Small End Width: 25.70mm/1.012in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 9000rpm

Packaging

• Quantity: Sold as a set of 5
• Package Size: 28CM*20CM*14CM
