Compatible Vehicles
- This motor is perfect for a wide range of applications, including water pumps, sprayers, harvesters, and grinders. Whether for agricultural or industrial use, this motor meets your needs and supports your projects with dependable performance.
Specification
- Frequency Rating：60 Hz
- Reversible/Non-Reversible：Reversible
- Nominal Rated Input Voltage：230V/460V
- Rated Load (HP)：1
- Special Motor Construction：Spindle Motor
- Shaft Diameter：５/8 in
- Enclosure Type： TEFC (Totally Enclosed Fan Cooled)
- Phase：Three Phase
- Insulation Class：F (Max 311°F)
- Mounting Type：Base-Mounted
- Pole :4
- Amps：3.8A / 1.9A
- Motor Type：Induction/Asynchronous
- Base RPM：1725RPM
- IP Rating：IP23
- Shaft Length：1.88in
- Protector：Non
- Housing Material：Rolled steel shell
- Model：General electric Motor
- IEC Frame Size：56C
Package included
- 1 x General electric Motor
- 1 x Manua
Note
Suggest using in clean and dry environments. Made of high-quality steel material, it can protect the engine, longer service life.
