Connecting Rods (with ARP bolts) Compatible for Fiat 2.0 Coupe 5-Cylinder 20V Turbo

Compatible Vehicles

• Compatible for Fiat 2.0L 20V Turbo L5 (175A3.000)
• Compatible for Fiat Coupe FA/175 1996-2000 Coupe (2.0 20V Turbo)
• Compatible for Fiat Coupe FA/175 1998-2000 Coupe (2.0 20V Turbo Plus)

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• ClearancedFor Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 3/8"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Upgrade Fasteners: ARP L19 (260,000 psi) optional
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Centre to Centre: 145.00mm / 5.709in
• Approximate Connecting Rod Weight:487g
• Big End Bore Diameter: 51.30mm / 2.020in
• Pin End Bore Diameter: 22.00mm / 0.866in
• Big End Width: 22.00mm / 0.866in
• Small End Width: 22.00mm / 0.866in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 9000rpm

Package included

• Quantity: Sold as a set of 5
• Package Size: 28CM*20CM*14CM
