Connecting Rods compatible for Audi B5 S4 Quattro 2.7T 154mm H-Beam Conrods ARP 2000 800HP

Compatible Vehicles

• Compatible for Audi B5 S4 quattro 2.7T
• compatible for VW Compatible for Audi A4 A6 V6 Engines 2.6L, 2.7 T 30V, 2.8L 12V

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• Clearanced for Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 5/16"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Upgrade Fasteners: ARP L19 (260,000 psi) optional
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Centre to Centre: 154.00mm/6.063in
• Approximate Connecting Rod Weight: 566g
• Big End Bore Diameter: 57.60mm/2.268in
• Pin End Bore Diameter: 21.00mm/0.827in
• Big End Width: 20.15mm/0.793in
• Small End Width: 21.95mm/0.864in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 7,000rpm

Packaging

• Quantity: Sold as a set of 6
• Package Size: 28CM*20CM*14CM
