Compatible for Toyota 2.2L MR2 Celica 5SFE forged high performance connecting rod rods

Compatible Vehicles

• Compatible for Toyota Camry MR2 Celica GT SX 5SFE 5S-FE 2.2L 4340 Forged

Specification

• TÜV Certification Con Rods
• Type: Forged 4340 aircraft chrome moly quality steel for racing
• H-beam Conrods Quantity: 4 Pieces a set
• Bolts:Including Genuine ARP 2000 bolts
• Note: Extra cost for upgrading to ARP L19 bolts
• Bolts Size: ARP 2000 3/8" bolts
• Tolerance: Balanced to +/- 1 gram in set
• Piston Bolt Hole: +-4/1000mm
• Power: 600hp ~ 800PS per set
• Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
• Top acceleration: 7000-9000rpm
• warranty: one year warranty for any manufacturing defect

Dimensions

• Centre to centre length: 138mm
• Big end diameter: 55mm
• Small end diameter: 22mm

Feature

• - Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
• - Designed and processed by CNC machine.
• - All big and small ends are finished with SUNNEN honing machine
• - Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
• - 100% X-rayed, sonic tested and magnafluxed
• - Multi-stage heat treated
• - Shot peened to relieve stress
• - Come with the bronzed bushing suitable for the floating piston pin

Note

• - Professional installation is highly recommended (No Instruction Included)
• - Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
