Compatible for Renault R5 Turbo 11 ARP 2000 Pleuel Bielle H-Beam Connecting Rod Conrod Con Rods

Compatible Vehicles

• Compatible for Renault R5 Turbo 11

Specification

• TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED
• Type: Forged 4340 aircraft chrome moly quality steel for racing
• H-beam Conrods Quantity: 4 Pieces a set
• Bolts: Including Genuine ARP 2000 bolts
• Note: Extra cost for upgrading to ARP L19 bolts
• Bolts Size: 3/8"
• Tolerance: Balanced to +/- 1 gram in set
• Bores finished to +/- .005mm
• Power: 600hp ~ 800PS per set
• Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
• Top acceleration: 9000rpm

Dimension

• Centre to centre length: 131mm
• Big end diameter: 47.614mm
• Small end diameter: 20mm
• Big end width: 21.8mm
• Small end width: 21.8mm

Feature

• - Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
• - Designed and processed by CNC machine.
• - All big and small ends are finished with SUNNEN honing machine
• - Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
• - 100% X-rayed, sonic tested and magnafluxed
• - Multi-stage heat treated
• - Shot peened to relieve stress
• - Come with the bronzed bushing suitable for the floating piston pin

Note

• Professional installation is highly recommended.
• If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
