Compatible for Isuzu Fargo Compatible for Holden 4ZB1 1.8L, 4ZC1 2.0L
Compatible for Isuzu Gemini G180 4ZB1 1.8L
Compatible for Isuzu Bellett G180 1.8L
Compatible for Isuzu Aska 4ZC1 2.0L
Compatible for Isuzu Piazza G200 4ZC1 2.0L
Compatible for Isuzu Trooper G200 2.0L
Specification
- Performance Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel for racing
- H-beam Conrods Quantity: 4 Pieces a set
- Bolts: Including Genuine ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: 3/8"
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Power: 600hp ~ 800PS per set
- Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 9000rpm
- Warranty: one year warranty for any manufacturing defect
Dimensions
Center to center length: 133.5mm
Big end diameter: 52mm
Small end diameter: 21.97mm
Big end width: XX
Small end width: XX
Feature
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Note
- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
