(Notice: This turbo is suitable for 4JH1TC 3.0L engine, not for 2.5L engine or 4JJ1TC/4JA1TC engine.)
Specification
Turbo Model:RHF5
Engine Code:4JH1T 4JH1TC 4JH1-T diesel engine
Cooling Type:Water+Oil Cooling
Bearing Type:Journal Bearing/Floating Bearing
Trust Bearing:360 degree
Horse Power:96kw / 130hp
Condition: 100% Brand New
Accessories: You will get what you can see in the pictures exactly
Package Size: 27 x 25 x 23 cm
Package Weight: 6100g
Feature
* Product Material
1. Turbine housing ：Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel：K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing：ZL104 aluminium with lightweight
4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance
* Product Performance
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance
* Product Certification: TÜV ISO 9001 CERTIFIED
* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer
Note
* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analysed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
OE/Part number
8973544234,897354-4234, 8-97354423-4,
8973659480,897365-9480, 8-97365948-0,
8973109482,897310-9482, 8-97310948-2,
8973109483,897310-9483, 8-97310948-3,
VA430065,VB430065, VA430077,VC430077,
VC430084,VB430093,VA430093,24123A,VIDW,VIEK,
(Notice:Not for turbo with following OE part number:8972402101,8973295881,8980115294)
