Compatible Vehicles
- Subaru Forester (SF) 1998-2002
SpecificationTop mounts
Pillow ball top mounts
Damping
24 levels rebound damping adjustable
Adjustable camber plate
No
Spring rate Front
9 kg/mm (514 lbs/in)
Spring rate Rear
7 kg/mm (392 lbs/in)
Spring length Front
190mm
Spring length Rear
220mm
Adjustable height
Lowering 1-3 inch
Coilover overall length Front
450mm-520mm
Coilover overall length Rear
600mm-690mm
Shock type
Twin tube
Spring Preload
7-10 mm
DimensionSize
62.5*50*20 cm
Weight
- 29.22 kg
- Feature1. Lowered height adjustment from 1" - 3" which allow a lower centre of gravity and also add a more aggressive stance
- 2. Adjustable pre-load spring tension to reduce the shaking motion to a certain extent
- 3. Adjustable Camber Plate and Pillow ball top mount for sharpening steering response.
- 4. 24 levels of adjustable damper -- This allows you the ability to perfectly dial in your coilovers system. For a nice comfortable driving, set damping to full soft. For more spirited driving, set it to 16 clicks. For occasional track days, set it to full stiff.
- 5. CNC machined Aluminium top mounts and lockers-- - excellent strength, and save weight
- 6. Heavy Duty Steel Lower Mounts--- Highly Durable & Reliable
- 7. Upgraded spring --- more than 600,000 times continuously test to assure its high tensile strength.
- 8. All inserts come with fitted long rubber boots--- To protect the damper better and be durable.
- 9. With a better damping setting, you will get better performance and comfort at the same time.
- 10. Twin-Tube structure ---provides excellent handling & control characteristics for most driving conditions
- 11. Corrosion Finish - Anodized Aluminium And Powder Coated Carbon Steel Parts
- 12. Test for the best---Every part were tested on our professional machine before being assembled and tested by our professional racers on road.
- 13. Clean room assembled---maintain a higher level of accuracy and reliability.
- 14. Upgraded damper oil---make damping more stable and smooth in a wide temperature range.
- Warranty: one year warranty for any manufacturing defectNotice
- All modifications must be installed by licensed mechanics and in compliance with your local modification regulations
