Brand New Connecting Rods compatible for BMW E36 E46 M52B28 Engine

Compatible Vehicles

• Compatible for BMW 3 Series E36 (1990-2000 325i / 328i) – Fits M50B25 / M52B28 / S52B32 / S52B30 / M54B30 engine
• compatible for BMW 3 Series E46 (1998-2007 325i / 328i / 330i / 325Ci / 328Ci / 330Ci / 325xi / 328xi / 330xi) – Fits M52B28 / M54B30 engine
• compatible for BMW 5 Series E12 (1972-1981 528i) – Fits M30B28 engine (not M50/M52/M54/S52 family)
• Compatible for BMW 7 Series E38 (1994-2001 728i / 728iL) – Fits M52B28 engine (detuned version)
• Compatible for BMW Z3 Coupe E36 (1997-2003 2.8i) – Fits M52B28 engine
• compatible for BMW Z3 Roadster E36 (1995-2003 2.8i) – Fits M52B28 / S52B32 engine (US market S52B32 in 1996-1999)
• Compatible for BMW 3 Series E36 (1996-1999 328i US spec) – Fits S52B32 3.2L engine (US M3)
• Pin Type: Floating Pin Piston（浮动活塞销）

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• Clearanced for Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 3/8"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Centre to Centre: 135.00mm/5.315in
• Approximate Connecting Rod Weight:561g
• Big End Bore Diameter: 48.00mm/1.890in
• Pin End Bore Diameter: 22.00mm/0.866in
• Big End Width: 21.90mm/0.862in
• Small End Width: 21.90mm/0.862in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 9000rpm

Packaging

• Quantity: Sold as a set of 6
• Package Size: 28CM*20CM*14CM
