4340 Forged Steel H-Beam Connecting Rods compatible for Ford Duratec 2.0L / Compatible for Mazda MZR 2.0L

Compatible Vehicles

• Compatible for Ford Focus LT / LS (2.0L) – Fits Duratec 2.0L engine
• compatible for Mazda 3 BK Series 2 (2.0L) – Fits MZR LF-VE 2.0L engine
• compatible for Mazda 3 BL Series 1 (2.0L) – Fits MZR LF-VE 2.0L engine
• compatible for Mazda 3 BL Series 2 (2.0L) – Fits MZR LF-VE 2.0L engine
• compatible for Mazda MX-5 NC (2.0L) – Fits MZR LF-VE 2.0L engine
• compatible for Mazda MX-5 NC Series II (2.0L) – Fits MZR LF-VE 2.0L engine

Specification

• Beam Style: H-beam Street/Strip
• Material: 4340 Chromoly Steel
• Finish: Shot-peened
• Wrist Pin Style: Floating
• Clearanced for Stroker: Yes
• Cap Retention Style: Through-bolt
• Connecting Rod Bolt Brand: ARP
• Connecting Rod Bolt Diameter: 3/8"
• Connecting Rod Bolt Material: Alloy Steel
• Fastener Yield Strength (psi): 220,000 psi (ARP 2000)
• Connecting Rod Bolt Head Style: 12-point
• CNC Machined: High Precision
• Rod Cap Alignment: Precision dowels
• Bore Tolerance: ±0.005 mm
• Balancing: ±1 gram per rod
• Weight Matched Set: Yes
• Remanufactured: No
• Testing: Magnafluxed, X-rayed, Ultrasonically tested
• Heat Treated: Yes

Dimension

• Connecting Rod Length Centre to Centre: 146.25mm/5.758in
• Approximate Connecting Rod Weight:566g
• Big End Bore Diameter: 50.04mm/1.984in
• Pin End Bore Diameter: 21.00mm/0.827in
• Big End Width：21.82mm/0.859in
• Small End Width: 18.03mm/0.710in

Performance Ratings

• Advertised Horsepower Rating: 200HP/piece
• Advertised RPM Rating: 9000rpm

Packaging

• Quantity: Sold as a set of 4
• Package Size: 28CM*20CM*10CM
