4340 EN24 Forged Steel H-Beam Connecting Rods compatible for BMW N54B30 3.0 E90 E91 E92

Compatible Vehicles

• Compatible for BMW N54B30 3.0 TURBO
• Engine:
• N54B30 3.0 L 2979 compatible for ccm 225 kW 306 hp from 2006
• N54B30 3.0 L 2979 compatible for ccm 243 kW 326 hp from 2008
• Fitment Details:
• Compatible for BMW 1 Series E82 Coupé 135i 2008–
• Compatible for BMW 1 Series E88 Convertible 135i 2008–
• Compatible for BMW 3 Series E90 Sedan 335i 2006–
• Compatible for BMW 3 Series E91 Touring 335i 2006–
• Compatible for BMW 3 Series E92 Coupé 335i 2006–
• Compatible for BMW 3 Series E93 Convertible 335i 2007–
• Compatible for BMW 5 Series E60 Sedan 535i 2008–
• Compatible for BMW 5 Series E61 Touring 535i 2008–
• Compatible for BMW 7 Series F01 Sedan 740i 2009–
• Compatible for BMW X6 E71
• compatible for BMW Z4 E89
• Pin Type: Floating Pin Piston

Specification

• *Type: Forged 4340 aircraft chrome moly quality steel for racing
• *H-beam Conrods Quantity: 6 Pieces as showing in picture
• *Bolts: Including ARP 2000 3/8" bolts  (Note: Extra cost for upgrading to ARP L19 bolts)
• *The connecting rods all include ARP 2000 bolts, which are rated at 220,000 psi, and the optional ARP L19 material at 260,000 psi is available as an upgraded product.
• *Advertised Horsepower Rating:200HP/piece
• *Top acceleration: 9000rpm
• *package size：28CM*21CM*14CM

Dimension

• Centre to centre length:145mm/5.709"
• Big end diameter:53.6mm/2.11"
• Small end diameter:22mm/0.866"(tapered small end)
• Big end width:20.8mm/0.819"
• Small end width:20.8mm/0.819"

Feature

• 1. TÜV PRODUCT TEST AND TÜV ISO 9001 CERTIFIED；
• 2. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing；
• 3. ARP 2000 bolts ,Optional ARP L19 fasteners available as an upgrade；
• 4. H-Beam design reduces weight without compromising strength；
• 5.Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers；
• 6.High precision CNC machined,Precision rod cap alignment dowels；
• 7.Bores finished to +/- .005mm；
• 8.Balanced to within +/- 1 g per rod；
• 9. Each rod is magnetic particle tested to ensure free of flaws；
• 10.Use X-rayed, sonic tested；
• 11.Custom Service.

Note

• *There are titanium-plated upgrade models；
• *Professional installation is highly recommended ；
• *Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
