Compatible Vehicles
- Compatible for Jeep Cherokee XJ 1984-2001 2WD
- compatible for Jeep Cherokee XJ 1984-2001 4WD
- Recommended tyre size: 31x10.50
- Wheel backspacing: 3.75"
Introduction
This complete package lift kit has everything you need for an exciting upgrade to our previous design. This lift kit includes a set of front lift springs and rear lift springs, which help level the vehicle while providing enough clearance to run up to 31" tyres. The high-pressure nitrogen-filled shocks provide a fantastic blend of off-road action and smooth on-road ride quality. With durable spring piston rods and a faster cooling shock body, the shocks provide up to 36kN of tensile strength for long life with impressive damping. Features natural rubber bushings and eye-catching metallic silver paint.
Specification
- Type: suspension lift level kit
- lift height: 3"
- Material: High Tensile Strength Steel
- Finish: Powder coated
- Bushing material: Rubber
- Diameter of piston rod: F&R 18mm/0.70"
- Piston diameter：F&R 35mm/1.37"
- Outer cylinder diameter: F&R 54mm/2.12"
- Travel: F: 247mm/9.72" R: 230mm/9.05"
- extended length:
- F: 697mm/27.44" R: 645mm/25.39"
- collapsed length:
- F: 450mm/17.71" R: 415mm/16.33"
- Nitrogen charged：yes
- dust cover equipped: yes
- front spring length: 500mm/19.68"
- front spring rate: 2.6kg/mm (145.59lbs/inch)
Feature
- -Easy bolt-on installation
- -Increased ground clearance
- -Levels the front with the rear of the vehicle
- -Maintains Smooth, Factory-Like Ride
Package included
- Front:
- 2x 3" lifted coil springs
- 2x front shocks
- Rear:
- 2x 1.5 - 2in add-a-leaf springs
- 2x rear shocks
- necessary hardware
